900XHH/1150XH Tier 4 Final Portable Lubricated Rotary Screw Air Compressor
Big Air is Back - And Better Than Ever
For jobs that require high volume air power, Sullair has you covered with the 900XHH/1150XH Tier 4 Final Portable Air Compressor. This compact machine fully embodies the Sullair brand promise: Reliability, Durability, Performance. Key features including:
- State-of-the-art 7" Sullair Touch Screen Controller (STS)
- Improved air flow capabilities
- Ease of access to maintenance items
Available with your choice of a reliable Caterpillar or Perkins engine!
Proven and Durable Package
- Legendary Sullair 25-Series Air End
- Highway towable running gear
- Improved 1500-hour air-oil separator design with lower compressor lubricant requirements
- Multiple lockable service doors
Choice of Reliable Caterpillar C15 or Perkins 2506J engines
- Tier 4 Final compliant
- Extended 500-hour engine oil service level
- 900 cfm at 500 psi
- 1150 cfm at 350 psi
- HPL 1500 High Pressure Portable Lubricant standard factory fill for compressor
Options & Extras
- Aftercooled
- Refinery package
Service Features & Options
- Fast evac oil change
- Maintenance kits available for service intervals from 50-2500 hours
Performance
- Actual Delivery cfm (m³/min): 900 (25.5)/1150 (32.6)
- Rated Pressure psig (bar): 500 (34.5)/350 (24.1)
- Pressure Range, max/min psig (bar): 500 (34.5) / 200 (13.8)
- Maximum Operating Altitude ft (m): 12,000 (3658)
- Fuel Consumption Full Load gal/h (l/h): 24 (90.8)/ 24.5 (92.7)
- Sound Level (U.S. EPA) dbA: 76
- Ambient Capability °F: -20 to 120
Engines
- Available Makes & Models (Emissions Level): Caterpillar C15 Diesel & Perkins 2506J Diesel (T4F)
- Displacement in³ (l): 928 (15.2)
- Cylinders: 6
- Bore x Stroke in (mm): 5.4 (137) x 6.73 (171)
- Operating Speed rpm: 1800
- Minimum Idle Speed rpm: 1400
- Available Power bhp (kW): 540 (403)
- Fuel Tank Capacity gal (l): 249 (943)
- DEF Capacity gal (l): 12.8 (48.4)
Weights & Dimensions
DTQ - Includes Running Gear
- Working weight lbs (kg): 18,980 (8627)
- Dry weight lbs (kg): 17,164 (7802)
- Length in (mm): 239 (6071)
- Width in (mm): 88 (2235)
- Height in (mm): 101 (2565)
DLQ - Less Running Gear
- Working weight lbs (kg):17,472 (7942)
- Dry weight lbs (kg): 15,656 (7116)
- Length in (mm): 208 (5283)
- Width in (mm): 88 (2235)
- Height in (mm): 89 (2261)
